4/5
فیلتر
| تعداد دندانه | قطر خارجی | قطر سوراخ | قطر متوسط | وزن | CAD |
|---|---|---|---|---|---|
| - | - | - | - | - | |
| 8 | 55.5 | 16 | 49.78 | 0.112 | |
| 9 | 62.5 | 16 | 55.70 | 0.158 | |
| 10 | 68.5 | 16 | 61.65 | 0.201 | |
| 11 | 74.5 | 16 | 67.62 | 0.249 | |
| 12 | 80.5 | 16 | 73.60 | 0.302 | |
| 13 | 86.5 | 16 | 79.60 | 0.360 | |
| 14 | 92.5 | 16 | 85.61 | 0.423 | |
| 15 | 98.5 | 20 | 91.63 | 0.480 | - |
| 16 | 104.5 | 20 | 97.65 | 0.553 | - |
| 17 | 110.5 | 20 | 103.67 | 0.630 | - |
| 18 | 116.5 | 20 | 109.70 | 0.712 | - |
| 19 | 122.5 | 20 | 115.74 | 0.799 | - |
| 20 | 129.5 | 20 | 121.78 | 0.908 | - |
| 21 | 135.5 | 20 | 127.82 | 1.005 | - |
| 22 | 141.5 | 20 | 133.86 | 1.107 | - |
| 23 | 147.5 | 20 | 139.90 | 1.214 | - |
| 24 | 153.5 | 20 | 145.95 | 1.326 | - |
| 25 | 159.5 | 20 | 151.99 | 1.443 | - |
| 26 | 165.5 | 20 | 158.04 | 1.564 | - |
| 27 | 171.5 | 25 | 164.09 | 1.676 | - |
| 28 | 177.5 | 25 | 170.14 | 1.807 | - |
| 29 | 183.5 | 25 | 176.19 | 1.943 | - |
| 30 | 189.5 | 25 | 182.25 | 2.084 | - |
| 31 | 195.5 | 25 | 188.30 | 2.230 | - |
| 32 | 201.5 | 25 | 194.35 | 2.381 | - |
| 33 | 207.5 | 25 | 200.41 | 2.536 | - |
| 34 | 214.5 | 25 | 206.46 | 2.725 | - |
| 35 | 220.5 | 25 | 212.52 | 2.891 | - |
| 36 | 226.5 | 25 | 218.57 | 3.062 | - |
| 37 | 232.5 | 25 | 224.63 | 3.238 | - |
| 38 | 238.5 | 25 | 230.69 | 3.419 | - |
| 39 | 244.5 | 25 | 236.74 | 3.604 | - |
| 40 | 250.5 | 25 | 242.80 | 3.794 | - |
| 41 | 256.5 | 25 | 248.86 | 3.989 | - |
| 42 | 262.5 | 25 | 254.92 | 4.189 | - |
| 43 | 268.5 | 25 | 260.98 | 4.394 | - |
| 44 | 274.5 | 25 | 267.03 | 4.604 | - |
| 45 | 280.5 | 25 | 273.09 | 4.819 | - |
| 46 | 286.5 | 25 | 279.15 | 5.038 | - |
| 47 | 292.5 | 25 | 285.21 | 5.262 | - |
| 48 | 298.5 | 25 | 291.27 | 5.491 | - |
| 49 | 305.5 | 25 | 297.33 | 5.766 | - |
| 50 | 311.5 | 25 | 303.39 | 6.006 | - |
| 51 | 317.5 | 25 | 309.45 | 6.250 | - |
| 52 | 323.5 | 25 | 315.51 | 6.500 | - |
| 53 | 329.5 | 25 | 321.57 | 6.754 | - |
| 54 | 335.5 | 25 | 327.63 | 7.013 | - |
| 55 | 341.5 | 25 | 333.69 | 7.277 | - |
| 56 | 347.5 | 25 | 339.75 | 7.545 | - |
| 57 | 353.5 | 25 | 345.81 | 7.819 | - |
| 58 | 359.5 | 25 | 351.87 | 8.097 | - |
| 59 | 365.5 | 25 | 357.93 | 8.380 | - |
| 60 | 371.5 | 25 | 363.99 | 8.668 | - |
| 61 | 377.5 | 25 | 370.06 | 8.961 | - |
| 62 | 383.5 | 25 | 376.12 | 9.259 | - |
| 63 | 389.5 | 25 | 382.18 | 9.562 | - |
| 64 | 396.5 | 25 | 388.24 | 9.923 | - |
| 65 | 402.5 | 25 | 394.30 | 10.236 | - |
| 66 | 408.5 | 25 | 400.36 | 10.554 | - |
| 67 | 414.5 | 25 | 406.42 | 10.877 | - |
| 68 | 420.5 | 25 | 412.49 | 11.204 | - |
| 69 | 426.5 | 25 | 418.55 | 11.537 | - |
| 70 | 432.5 | 25 | 424.61 | 11.874 | - |
| 71 | 438.5 | 25 | 430.67 | 12.216 | - |
| 72 | 444.5 | 25 | 436.73 | 12.564 | - |
| 73 | 450.5 | 25 | 442.79 | 12.915 | - |
| 74 | 456.5 | 25 | 448.86 | 13.272 | - |
| 75 | 462.5 | 25 | 454.92 | 13.634 | - |
| 76 | 468.5 | 25 | 460.98 | 14.000 | - |
| 77 | 474.5 | 25 | 467.04 | 14.372 | - |
| 78 | 480.5 | 25 | 473.10 | 14.748 | - |
| 79 | 486.5 | 25 | 479.17 | 15.129 | - |
| 80 | 493.5 | 25 | 485.23 | 15.581 | - |
| 81 | 499.5 | 25 | 491.29 | 15.973 | - |
| 82 | 505.5 | 25 | 497.35 | 16.369 | - |
| 83 | 511.5 | 25 | 503.42 | 16.770 | - |
| 84 | 517.5 | 25 | 509.48 | 17.176 | - |
| 85 | 523.5 | 25 | 515.54 | 17.587 | - |
| 86 | 529.5 | 25 | 521.60 | 18.003 | - |
| 87 | 535.5 | 25 | 527.67 | 18.424 | - |
| 88 | 541.5 | 25 | 533.73 | 18.849 | - |
| 89 | 547.5 | 25 | 539.79 | 19.280 | - |
| 90 | 553.5 | 25 | 545.85 | 19.715 | - |
| 91 | 559.5 | 25 | 551.92 | 20.155 | - |
| 92 | 565.5 | 25 | 557.98 | 20.600 | - |
| 93 | 571.5 | 25 | 564.04 | 21.049 | - |
| 94 | 577.5 | 25 | 570.10 | 21.504 | - |
| 95 | 584.5 | 25 | 576.17 | 22.042 | - |
| 96 | 590.5 | 25 | 582.23 | 22.507 | - |
| 97 | 596.5 | 25 | 588.29 | 22.977 | - |
| 98 | 602.5 | 25 | 594.35 | 23.452 | - |
| 99 | 608.5 | 25 | 600.42 | 23.932 | - |
| 100 | 614.5 | 25 | 606.48 | 24.416 | - |
| 101 | 620.5 | 25 | 612.54 | 24.905 | - |
| 102 | 626.5 | 25 | 618.61 | 25.400 | - |
| 103 | 632.5 | 25 | 624.67 | 25.899 | - |
| 104 | 638.5 | 25 | 630.73 | 26.403 | - |
| 105 | 644.5 | 25 | 636.79 | 26.911 | - |
| 106 | 650.5 | 25 | 642.86 | 27.425 | - |
| 107 | 656.5 | 25 | 648.92 | 27.943 | - |
| 108 | 662.5 | 25 | 654.98 | 28.467 | - |
| 109 | 668.5 | 25 | 661.05 | 28.995 | - |
| 110 | 674.5 | 25 | 667.11 | 29.528 | - |
| 111 | 681.5 | 25 | 673.17 | 30.157 | - |
| 112 | 687.5 | 25 | 679.24 | 30.701 | - |
| 113 | 693.5 | 25 | 685.30 | 31.249 | - |
| 114 | 699.5 | 25 | 691.36 | 31.802 | - |
| 115 | 705.5 | 25 | 697.42 | 32.360 | - |
| 116 | 711.5 | 25 | 703.49 | 32.923 | - |
| 117 | 717.5 | 25 | 709.55 | 33.491 | - |
| 118 | 723.5 | 25 | 715.61 | 34.063 | - |
| 119 | 729.5 | 25 | 721.68 | 34.641 | - |
| 120 | 735.5 | 25 | 727.74 | 35.223 | - |
| 121 | 741.5 | 25 | 733.80 | 35.810 | - |
| 122 | 747.5 | 25 | 739.87 | 36.402 | - |
| 123 | 753.5 | 25 | 745.93 | 36.999 | - |
| 124 | 759.5 | 25 | 751.99 | 37.601 | - |
| 125 | 765.5 | 25 | 758.06 | 38.207 | - |
| 126 | 772.5 | 25 | 764.12 | 38.923 | - |
| 127 | 778.5 | 25 | 770.18 | 39.540 | - |
| 128 | 784.5 | 25 | 776.24 | 40.162 | - |
| 129 | 790.5 | 25 | 782.31 | 40.788 | - |
| 130 | 796.5 | 25 | 788.37 | 41.420 | - |
هیچ تنوعی با فیلترهای انتخابی یافت نشد.
